Guardian Lifts 10k 2-post (Overhead)
1/16
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
  • Guardian Lifts 10k 2-post (Overhead)
Guardian Lifts 10k 2-post (Overhead)

Guardian Lifts 10k 2-post (Overhead)
$3,995.00 + Freight

Guardian GL-10-OH 10,000 lb. 2-Post Lift

The Guardian GL-10-OH is a dependable 2-post lift built for cars, SUVs, and light-duty trucks. With a 10,000 lb. lifting capacity, it’s ideal for routine service and repair work in home garages or professional shops.

Designed for strength and ease of use, it features 3-stage arms with a low 3.75" pad height, "excellent for low profile vehicles", reinforced single-piece columns, and a single-point overhead lock release for quick operation.

Key Features:

  • 3-stage arms with low 3.75" profile
  • Single-point overhead lock release
  • Reinforced single-piece column design
  • “S” style column construction for added stability
  • Screw-up universal pads
  • Stack-on truck adapters included
  • ETL-recognized 220V power unit
  • Includes mounting hardware and shims
  • 7- year limited warranty

Installation Requirements:
Requires a minimum ceiling height of 12 ft. and a 4.5" thick concrete slab rated at 3,500+ PSI, free of cracks or seams.

Installation available in most areas.

Our lifts are designed for convenience, safety, and versatility — perfect for garages of any size.

Guardian Lifts 10k 2-post (Overhead) is equipped with:

  • ✔ 10,000 LBS lifting capacity
  • ✔ Symmetric lifting configuration
  • ✔ 3 Stage Front/Rear adjustable arms
  • ✔ Low-profile pad height (3.75")
  • ✔ Approx. 43 seconds lift speed
  • ✔ 240V/ 20 AMPS/ 1PH standard motor

Product Specifications for Guardian Lifts 10k 2-post (Overhead)

Lifting Capacity10,000 LBS
Lifting ConfigurationSymmetric
Arms3 Stage Front/Rear
Rise Height74.75"/6'2.75"
Overall Height142"/ 11'10"
Drive-Thru Clearance101.5"/ 8'5.5"
Floor to Overhead Switch136"/ 11'4"
Front Arm Reach24.75"-42.5"/ 2'0.75"-3'6.5"
Rear Arm Reach31.25"-59"/ 2'7.25"-4'11
Min. Pad Height3.75"
Inside Columns110.5"/ 9'2.5"
Motor / Voltage240V/ 20 AMPS/ 1PH
Speed of RiseApprox. 43 seconds
Ceiling Height Requirement144" / 12"
Shipping Weight1,655 LBS
Shipping Dimensions (L × W × H)144" x 20" x 58"/ 12' x 1'8" x4'10"

Schematic Diagram

Schematic preview for Guardian Lifts 10k 2-post (Overhead)
Click image to download full schematic (PDF)
